Technical data-sheet
MW-123 32A 3 PIN Wall Socket
Makewell Tech’s 32A 3 Pin Wall Socket provides reliable, high-capacity power distribution for heavy-duty industrial and commercial applications. Built tough for safety and performance.
The Makewell Tech 32A 3 Pin Wall Socket is engineered to deliver safe, dependable, and consistent power in the most demanding environments. Whether installed in a factory, workshop, or construction site, this heavy-duty socket is purpose-built to handle high-current loads while ensuring user safety and equipment reliability.
Designed for Professional Performance
Unlike conventional wall outlets, this industrial-grade socket is optimized for continuous operation at 32 amps. It provides robust, secure connections to power heavy machinery, high-wattage tools, and production equipment that require stable, uninterrupted electricity.
With its rugged construction and superior contact reliability, this socket helps prevent downtime and supports safe, efficient workflows.
Key Features and Benefits
- 32A Current Capacity
Handles high-power loads effortlessly, making it ideal for energy-intensive equipment and three-phase installations. - 3 Pin Configuration
Includes live, neutral, and earth pins to ensure proper grounding and compliance with international safety standards. - Impact-Resistant Housing
Manufactured from high-quality thermoplastic that withstands impact, vibration, and temperature extremes. - Secure Connection Mechanism
Precision-engineered contacts deliver a tight, vibration-resistant fit with compatible 32A 3 Pin plugs, preventing accidental disconnections and arcing. - Splash-Proof Protection
Ingress protection (IP44 or higher) guards against dust and splashes, making this wall socket suitable for semi-outdoor or rugged industrial environments. - Easy Installation and Maintenance
Ergonomic design and clear terminal markings reduce installation time and minimize the risk of wiring errors.
Applications Across Industries
Makewell Tech’s 32A 3 Pin Wall Socket is trusted in a wide range of applications, including:
- Manufacturing Plants: Powering conveyor systems, production lines, and large machinery.
- Workshops: Supplying energy to welders, industrial saws, and high-capacity tools.
- Construction Sites: Connecting heavy-duty site equipment, lighting, and temporary power boards.
- Warehouses: Running forklifts, chargers, and material handling equipment.
- Agriculture: Operating irrigation pumps and processing equipment in rugged environments.
Technical Specifications
- Brand: Makewell Tech
- Current Rating: 32A
- Voltage: 220–250V
- Pins: 3 (Live, Neutral, Earth)
- Material: Industrial-grade thermoplastic
- Ingress Protection: IP44 or higher (depending on the model)
- Operating Temperature: -25°C to +40°C
- Standards Compliance: IEC/EN 60309
- Mounting: Wall installation with secure fixing points
Easy Installation
Installing the Makewell Tech 32A 3 Pin Wall Socket is straightforward:
- Prepare Wiring: Strip insulation to expose conductors.
- Connect Terminals: Insert each conductor into clearly labeled terminals (L, N, E) and tighten screws securely.
- Mount the Socket: Fix to a stable wall surface or panel with the provided fasteners.
- Test Connections: Always verify wiring with a continuity tester before energizing.
- Important: Installation must be performed by a qualified electrician to meet safety standards.
Why Choose Makewell Tech?
Makewell Tech is committed to engineering robust, reliable electrical products that professionals can trust. The 32A 3 Pin Wall Socket combines industrial-grade performance, proven safety, and easy installation to keep your operations running smoothly—day after day.
