MW-0252 32A 5 PIN Plug

The Makewell Tech IP67 Series 32A 5 Pin Plug is built for professionals who require safe, reliable, and high-capacity power connections in the most demanding industrial and outdoor environments. Engineered to withstand exposure to dust, water, and harsh conditions, this connector ensures your equipment stays powered without interruption.

Built for Extreme Conditions

Rated for 32 amps, this industrial plug is perfect for supplying three-phase electricity to machinery, portable tools, and equipment that require consistent, high-capacity power. The IP67 ingress protection guarantees total protection against dust and immersion in water up to 1 meter for 30 minutes, making it an ideal solution for outdoor installations, washdown areas, and wet locations.

The rugged housing is crafted from high-impact thermoplastic, delivering outstanding durability and resistance to impacts, vibrations, chemicals, and UV exposure. Whether you are working on a construction site, at a marine dock, or in a factory, you can trust this connector to perform reliably every day.

Key Features and Benefits

• 32A High-Current Capacity
  Handles demanding three-phase loads safely and efficiently, maintaining stable power without overheating.
• 5 Pin Configuration
  Includes three phase pins (L1, L2, L3), neutral, and earth pins for balanced power distribution and safe grounding in compliance with IEC/EN 60309 standards.
• IP67 Dust-Tight & Waterproof Protection
  Fully sealed housing prevents dust ingress and withstands water immersion, ensuring safe operation in any environment.
• Rugged Construction
  High-quality thermoplastic housing resists impacts, chemical exposure, and extreme temperatures.
• Secure Locking Mechanism
  Precision-engineered contacts create a tight, vibration-resistant connection that minimizes the risk of accidental disconnection.
• Ergonomic Design
  Ribbed grips and clearly labeled terminals make handling, wiring, and maintenance straightforward and safe.

Typical Applications

Makewell Tech’s IP67 Series 32A 5 Pin Plug is trusted across a wide range of industries and installations:

• Manufacturing Facilities: Connecting production machinery, conveyor systems, and processing equipment.
• Construction Sites: Powering lighting rigs, heavy-duty tools, and mobile generators.
• Warehouses: Running chargers, automated handling systems, and forklifts.
• Marine and Docks: Supplying safe shore power connections and dockside equipment.
• Agriculture: Operating irrigation pumps, grain dryers, and processing machinery outdoors.

Technical Specifications

1. Brand: Makewell Tech
2. Series: IP67
3. Current Rating: 32A
4. Voltage: 380–415V (three-phase)
5. Pins: 5 (3 phase + neutral + earth)
6. Material: High-impact thermoplastic
7. Ingress Protection: IP67 (dust-tight and waterproof)
8. Operating Temperature: -25°C to +40°C
9. Standards Compliance: IEC/EN 60309

Easy Installation

Installing the Makewell Tech IP67 Series 32A 5 Pin Plug is simple and safe:

• Prepare the Cable: Strip insulation to expose conductors.
• Wire the Terminals: Insert wires into the clearly marked terminals (L1, L2, L3, N, E) and tighten screws securely.
• Assemble the Housing: Close and lock the body to maintain the waterproof seal.
• Test the Connection: Always use a continuity tester to verify correct wiring before energizing.
• Important: Installation must be carried out by a qualified electrician to comply with safety standards.

Why Choose Makewell Tech?

Makewell Tech is dedicated to delivering professional-grade power solutions that combine durability, safety, and ease of use. The IP67 Series 32A 5 Pin Plug is your reliable choice for powering critical equipment in harsh environments—ensuring operations run smoothly and safely every day.
