MW-1252 32A 5 PIN Wall Socket

The Makewell Tech IP67 Series 32A 5 Pin Wall Socket is engineered to deliver safe, dependable, and high-capacity power connections in the toughest environments. Designed for professionals who demand maximum performance, this robust socket provides consistent three-phase power, ensuring equipment runs reliably no matter the conditions.

Built for Harsh Environments

Rated for 32 amps, this heavy-duty socket is ideal for powering industrial machinery, production lines, mobile equipment, and large tools that require continuous and stable electricity. With its IP67 ingress protection, it offers complete dust-tight sealing and protection against immersion in water up to 1 meter, making it perfect for wet, dusty, and outdoor applications.

The housing is constructed from high-impact thermoplastic, providing superior resistance to impacts, vibrations, UV rays, and harsh chemicals. Whether you are installing in a factory, warehouse, shipyard, or construction site, you can count on this wall socket to deliver safe and reliable performance.

Key Features and Benefits

• 32A High-Current Capacity
  Safely delivers continuous power for demanding equipment without overheating or performance degradation.
• 5 Pin Configuration
  Includes three phase pins (L1, L2, L3), a neutral pin, and an earth pin for balanced power and complete grounding protection, fully compliant with IEC/EN 60309 standards.
• IP67 Dust-Tight & Waterproof Protection
  Fully sealed design prevents dust ingress and withstands water immersion, ensuring safe operation in all environments.
• Rugged Thermoplastic Housing
  Resists impacts, abrasion, and chemical exposure for maximum durability and long life.
• Secure Connection Mechanism
  Precision-engineered contacts create a firm, vibration-resistant fit with compatible plugs, reducing the risk of accidental disconnections.
• Ergonomic Design
  Clearly labeled terminals and ribbed grips simplify wiring, maintenance, and inspection.

Typical Applications

Makewell Tech’s IP67 Series 32A 5 Pin Wall Socket is trusted across industries, including:

• Manufacturing Facilities: Powering conveyor systems, industrial machines, and processing equipment.
• Construction Sites: Delivering safe power to lighting rigs, mixers, and portable tools in outdoor areas.
• Warehouses: Operating chargers, automated systems, and material handling equipment.
• Marine & Docks: Providing secure shore power connections and dockside equipment hookups.
• Agriculture: Powering irrigation pumps, grain dryers, and outdoor machinery.

Technical Specifications

1. Brand: Makewell Tech
2. Series: IP67
3. Current Rating: 32A
4. Voltage: 380–415V (three-phase)
5. Pins: 5 (3 phase + neutral + earth)
6. Material: High-impact thermoplastic
7. Ingress Protection: IP67 (dust-tight and waterproof)
8. Operating Temperature: -25°C to +40°C
9. Standards Compliance: IEC/EN 60309
10. Mounting: Wall installation with secure fixing points

Easy and Safe Installation

Installing the Makewell Tech IP67 Series 32A 5 Pin Wall Socket is straightforward:

• Prepare the Wiring: Strip insulation to expose the conductors.
• Connect the Terminals: Insert each conductor into the clearly marked terminals (L1, L2, L3, N, E) and tighten all screws securely.
• Mount the Socket: Fix securely to a stable wall or panel using appropriate fasteners.
• Test Connections: Always verify continuity and correct wiring before energizing.
• Important: Installation must be performed by a qualified electrician to ensure compliance with safety standards.

Why Choose Makewell Tech?

At Makewell Tech, we are committed to delivering products that combine rugged durability, certified safety, and long-term performance. The IP67 Series 32A 5 Pin Wall Socket is your reliable choice for three-phase power connections that work—rain or shine, indoors or out.
