MW-2252 32A 5 PIN Connector

The Makewell Tech IP67 Series 32A 5 Pin Connector is engineered to deliver safe, reliable, and high-capacity power connections in the toughest industrial and outdoor applications. Whether you need dependable electricity in a factory, on a construction site, or in an agricultural facility, this heavy-duty connector ensures your equipment stays powered without compromise.

Engineered for Extreme Conditions

Rated for 32 amps, this connector is perfect for medium- to heavy-duty three-phase installations that require continuous, stable power. The IP67 ingress protection offers total protection against dust ingress and allows for immersion in water up to 1 meter for 30 minutes, making it ideal for wet, dusty, and harsh environments where conventional connectors fall short.

Crafted from high-impact thermoplastic, the housing withstands impact, vibration, UV exposure, and chemicals, delivering years of dependable service even in the most challenging conditions.

Key Features and Benefits

• 32A High-Current Capacity
  Safely supplies stable, efficient power to heavy-duty machinery, production lines, and industrial tools.
• 5 Pin Configuration
  Includes three phase pins (L1, L2, L3), neutral, and earth pins for balanced three-phase power distribution and proper grounding compliant with IEC/EN 60309 standards.
• IP67 Dust-Tight & Waterproof Protection
  Fully sealed housing guards internal connections from dust, dirt, and water ingress, supporting safe operation in any environment.
• Rugged Thermoplastic Housing
  Resistant to impact, abrasion, and chemicals, providing reliable performance even in outdoor and industrial settings.
• Secure Locking System
  Precision-engineered contacts maintain a tight, vibration-resistant fit with matching plugs and sockets, reducing the risk of accidental disconnections.
• Ergonomic Design
  Clearly marked terminals and ribbed grips simplify handling, wiring, and maintenance.

Typical Applications

The Makewell Tech IP67 Series 32A 5 Pin Connector is trusted across industries including:

• Manufacturing Facilities: Connecting heavy-duty machines, conveyors, and production systems.
• Construction Sites: Powering lighting rigs, portable equipment, and site installations exposed to weather.
• Warehouses: Operating chargers, handling systems, and automated machinery.
• Agriculture: Running irrigation pumps, grain dryers, and outdoor processing systems.
• Marine & Docks: Providing safe shore power connections and equipment hookups in wet conditions.

Technical Specifications

1. Brand: Makewell Tech
2. Series: IP67
3. Current Rating: 32A
4. Voltage: 380–415V (three-phase)
5. Pins: 5 (3 phase + neutral + earth)
6. Material: High-impact thermoplastic
7. Ingress Protection: IP67 (dust-tight and waterproof)
8. Operating Temperature: -25°C to +40°C
9. Standards Compliance: IEC/EN 60309

Simple and Safe Installation

Installing the Makewell Tech IP67 Series 32A 5 Pin Connector is fast and secure:

• Prepare Cable: Strip insulation to expose conductors.
• Wire Terminals: Insert each conductor into the clearly labeled terminals (L1, L2, L3, N, E) and tighten screws securely.
• Assemble Housing: Close and lock the housing to maintain waterproof protection.
• Test Connections: Use a continuity tester to verify correct wiring before energizing.
• Important: Installation must always be carried out by a qualified electrician to comply with safety regulations.

Why Choose Makewell Tech?

At Makewell Tech, we build products that combine engineering excellence with proven durability and safety. The IP67 Series 32A 5 Pin Connector is your reliable solution for powering critical equipment in the harshest conditions—indoors or out.
