Technical data-sheet
MW-1232 32A 3 PIN Wall Socket
Makewell Tech’s 32A 3 Pin Wall Socket delivers safe, high-capacity power distribution for industrial and commercial installations. Built for durability and reliable performance.
The Makewell Tech 32A 3 Pin Wall Socket is engineered to deliver reliable, efficient, and safe power distribution in demanding industrial and commercial environments. Designed for medium- to heavy-duty electrical loads, this rugged socket ensures your equipment operates at peak performance every day.
Built for Demanding Applications
Rated for 32 amps, this wall socket is ideal for supplying power to industrial machinery, production equipment, and high-capacity tools that require consistent energy delivery. Whether installed in a workshop, manufacturing plant, or construction site, it provides dependable electrical performance under continuous load.
The housing is crafted from high-impact thermoplastic, offering outstanding resistance to impacts, vibration, temperature fluctuations, and chemical exposure. Its robust design ensures long service life and reliable operation, even in harsh environments.
Key Features and Benefits
- 32A Current Capacity
Handles medium- to high-power equipment safely, delivering stable power without overheating. - 3 Pin Configuration
Includes live, neutral, and earth pins, ensuring proper grounding and compliance with IEC/EN 60309 standards. - Rugged Construction
Impact-resistant thermoplastic housing protects internal components from mechanical stress and environmental hazards. - Ingress Protection
IP44-rated design shields connections from dust and water splashes, supporting semi-outdoor installations. - Secure Connection Mechanism
Precision-engineered contacts ensure a tight, vibration-resistant fit with compatible plugs, reducing the risk of accidental disconnections. - Easy Installation
Clearly marked terminals and an ergonomic layout make wiring, installation, and maintenance simple and efficient.
Typical Applications
Makewell Tech’s 32A 3 Pin Wall Socket is trusted in many industries, including:
- Manufacturing Facilities: Powering conveyor systems, production lines, and industrial machinery.
- Construction Sites: Supplying electricity to lighting systems, heavy-duty tools, and temporary installations.
- Workshops: Running welding equipment, compressors, and large saws.
- Warehouses: Operating material handling systems, chargers, and automated machinery.
- Agriculture: Delivering power to irrigation pumps and processing equipment.
Technical Specifications
- Brand: Makewell Tech
- Current Rating: 32A
- Voltage: 220–250V
- Pins: 3 (Live, Neutral, Earth)
- Material: High-impact thermoplastic
- Ingress Protection: IP44
- Operating Temperature: -25°C to +40°C
- Standards Compliance: IEC/EN 60309
- Mounting: Wall installation with secure fixing points
Easy and Safe Installation
Installing the Makewell Tech 32A 3 Pin Wall Socket is fast and secure:
- Prepare the Wiring: Strip insulation to expose conductors.
- Connect Terminals: Insert conductors into clearly marked terminals (L, N, E) and tighten screws firmly.
- Mount the Socket: Fix to a stable wall or panel using appropriate fasteners.
- Test the Connection: Use a continuity tester to confirm correct wiring before energizing.
- Important: Installation must be performed by a qualified electrician to ensure compliance with all safety standards.
Why Choose Makewell Tech?
At Makewell Tech, we combine engineering excellence with a commitment to safety, durability, and ease of use. The 32A 3 Pin Wall Socket offers reliable, high-capacity power distribution that professionals trust to keep their operations running efficiently and safely.
