Technical data-sheet
MW-3252 32A 5 PIN Panel Socket
Makewell Tech’s IP67 Series 32A 5 Pin Panel Socket provides waterproof, dust-tight, and reliable three-phase power distribution for industrial control panels and enclosures.
The Makewell Tech IP67 Series 32A 5 Pin Panel Socket is engineered to provide secure, efficient, and heavy-duty three-phase power connections in the most demanding environments. Designed for industrial panels, machinery enclosures, and distribution boards, this socket delivers reliable performance, rain or shine.
Built for Extreme Conditions
With a 32A current rating, this socket safely powers medium- to heavy-duty equipment, including production lines, motors, and processing systems. The IP67 ingress protection ensures total dust-tight sealing and protection against immersion in water up to 1 meter, making it ideal for outdoor installations, washdown areas, and dusty production floors.
The housing is crafted from high-impact thermoplastic, delivering excellent resistance to vibration, mechanical stress, temperature extremes, and chemical exposure. Whether mounted indoors or out, it guarantees reliable, long-lasting performance.
Key Features and Benefits
- 32A High-Current Capacity
Supports demanding three-phase applications without overheating, ensuring stable power for critical equipment. - 5 Pin Configuration
Includes three phase pins (L1, L2, L3), neutral, and earth pins, providing balanced power distribution and safe grounding, compliant with IEC/EN 60309 standards. - IP67 Dust-Tight & Waterproof Protection
Sealed design keeps out dust, dirt, and water, supporting safe use in harsh and wet environments. - Rugged Construction
High-quality thermoplastic housing resists impacts, abrasion, UV rays, and chemicals. - Secure Connection Mechanism
Precision-engineered contacts create a tight, vibration-resistant fit with compatible plugs, reducing accidental disconnections. - User-Friendly Design
Clearly marked terminals and ergonomic layout simplify wiring, reduce installation time, and improve safety.
Typical Applications
Makewell Tech’s IP67 Series 32A 5 Pin Panel Socket is trusted across industries:
- Manufacturing Plants: Distributing three-phase power to conveyors, processing machines, and industrial ovens.
- Construction Sites: Powering lighting rigs, mixers, and site installations in outdoor areas.
- Warehouses: Operating chargers, handling systems, and automated equipment.
- Marine & Docks: Providing shore power connections and safe dockside distribution.
- Agriculture: Running irrigation pumps, dryers, and processing systems exposed to dust and moisture.
Technical Specifications
- Brand: Makewell Tech
- Series: IP67
- Current Rating: 32A
- Voltage: 380–415V (three-phase)
- Pins: 5 (3 phase + neutral + earth)
- Material: High-impact thermoplastic
- Ingress Protection: IP67 (dust-tight and waterproof)
- Operating Temperature: -25°C to +40°C
- Standards Compliance: IEC/EN 60309
- Mounting: Panel installation with secure fixing points
Easy and Safe Installation
Installing the Makewell Tech IP67 Series 32A 5 Pin Panel Socket is fast and secure:
- Prepare the Panel: Cut an opening to the specified dimensions.
- Wire Terminals: Strip insulation and insert conductors into the clearly marked terminals (L1, L2, L3, N, E).
- Secure the Terminals: Tighten screws to create a solid electrical connection.
- Mount the Socket: Fix into place with appropriate hardware.
- Test Connections: Always verify wiring and continuity before energizing.
- Important: Installation should be performed by a qualified electrician to comply with safety standards.
Why Choose Makewell Tech?
At Makewell Tech, we combine engineering expertise with a commitment to safety and durability. The IP67 Series 32A 5 Pin Panel Socket ensures you have a reliable, waterproof solution for powering your operations—indoors or outdoors.
