Technical data-sheet
MW-2232 32A 3 PIN Connector
Makewell Tech’s 32A 3 Pin Connector provides safe, high-capacity power connections for industrial and commercial equipment. Engineered for durability and consistent performance.
The Makewell Tech 32A 3 Pin Connector is engineered to deliver safe, stable, and reliable power connections in demanding industrial and commercial environments. When your operations rely on uninterrupted electricity for equipment and machinery, this rugged connector ensures you stay productive without compromise.
Designed for Professional Performance
With a 32-amp current rating, this connector is ideal for powering medium- to heavy-duty systems, including large machinery, conveyor systems, industrial tools, and high-capacity equipment. Whether installed in a factory, workshop, or on a construction site, it provides consistent electrical performance under continuous loads.
The housing is crafted from high-impact thermoplastic, which resists mechanical stress, vibration, and harsh environmental exposure. This ensures the connector maintains structural integrity and electrical safety even in challenging applications.
Key Features and Benefits
- 32A Current Capacity
Handles high-demand equipment safely and efficiently, providing stable power without overheating. - 3 Pin Configuration
Includes live, neutral, and earth pins to deliver balanced power distribution and proper grounding, compliant with IEC/EN 60309 standards. - Robust Construction
Heavy-duty thermoplastic housing withstands impacts, chemicals, and temperature variations, extending service life. - Ingress Protection
IP44-rated design protects internal connections from dust ingress and water splashes, making it suitable for semi-outdoor use. - Secure Connection Mechanism
Precision-engineered contacts ensure a tight, vibration-resistant fit with compatible plugs and sockets, reducing the risk of accidental disconnections. - Easy Installation and Handling
Clear terminal markings and ergonomic grips simplify wiring, inspection, and maintenance, saving time and reducing installation errors.
Typical Applications
The Makewell Tech 32A 3 Pin Connector is trusted by professionals across industries such as:
- Manufacturing Plants: Connecting production lines, conveyors, and industrial machinery.
- Construction Sites: Powering site tools, lighting systems, and portable equipment.
- Warehouses: Operating chargers, material handling systems, and automation equipment.
- Workshops: Supplying power to welding machines, compressors, and large saws.
- Agriculture: Running irrigation pumps, dryers, and processing machines.
Technical Specifications
- Brand: Makewell Tech
- Current Rating: 32A
- Voltage: 220–250V
- Pins: 3 (Live, Neutral, Earth)
- Material: High-impact thermoplastic
- Ingress Protection: IP44
- Operating Temperature: -25°C to +40°C
- Standards Compliance: IEC/EN 60309
Simple and Safe Installation
Installing the Makewell Tech 32A 3 Pin Connector is straightforward:
- Prepare the Cable: Strip insulation to expose conductors.
- Wire Terminals: Insert conductors into clearly labeled terminals (L, N, E) and tighten screws securely.
- Assemble Housing: Close and lock the body to maintain protection.
- Test the Connection: Always verify correct wiring with a continuity tester before energizing.
- Important: Installation must be performed by a qualified electrician to comply with safety standards.
Why Choose Makewell Tech?
Makewell Tech combines engineering expertise with a commitment to quality and safety. The 32A 3 Pin Connector is the reliable, heavy-duty solution professionals trust to power essential equipment and maintain productivity in any environment.
