Technical data-sheet
MW-3232 32A 3 PIN Panel Socket
Makewell Tech’s 32A 3 Pin Panel Socket delivers reliable, high-capacity power distribution for industrial control panels and enclosures. Built tough for dependable performance.
The Makewell Tech 32A 3 Pin Panel Socket is designed to deliver safe, efficient, and dependable power distribution in the most demanding industrial and commercial environments. Engineered for reliability and ease of installation, this robust socket ensures your critical equipment operates consistently and safely.
Built for Heavy-Duty Applications
Rated for 32 amps, this panel socket is ideal for supplying power to medium- and high-capacity machines, production equipment, and professional tools. Whether you’re installing it in a control panel, distribution board, or machinery enclosure, it provides stable electrical performance under continuous load without risk of overheating.
The housing is crafted from high-impact thermoplastic, offering excellent resistance to mechanical stress, temperature extremes, vibration, and chemical exposure. This durable construction guarantees long service life and dependable operation even in harsh industrial settings.
Key Features and Benefits
- 32A Current Capacity
Delivers stable power to support demanding applications such as conveyors, motors, and processing equipment. - 3 Pin Configuration
Includes live, neutral, and earth pins, providing safe grounding and compliance with IEC/EN 60309 standards. - Robust Thermoplastic Housing
Resists impacts, abrasion, and harsh environments, ensuring consistent performance over time. - Ingress Protection
IP44-rated to protect against dust and splashing water, making it suitable for semi-outdoor and industrial use. - Secure Connection Mechanism
Precision-engineered contacts provide a firm, vibration-resistant fit with compatible plugs, reducing the risk of accidental disconnections. - User-Friendly Design
Clearly marked terminals and an ergonomic layout simplify wiring, speed up installation, and reduce the potential for errors.
Typical Applications
Makewell Tech’s 32A 3 Pin Panel Socket is trusted across industries and applications, including:
- Manufacturing Facilities: Powering production lines, conveyor systems, and industrial machinery.
- Workshops: Connecting heavy-duty tools, welding machines, and compressors.
- Warehouses: Supplying power to chargers, handling systems, and automated equipment.
- Construction Sites: Distributing electricity to site tools, lighting, and temporary installations.
- Agriculture: Operating irrigation pumps and grain processing machinery.
Technical Specifications
- Brand: Makewell Tech
- Current Rating: 32A
- Voltage: 220–250V
- Pins: 3 (Live, Neutral, Earth)
- Material: High-impact thermoplastic
- Ingress Protection: IP44
- Operating Temperature: -25°C to +40°C
- Standards Compliance: IEC/EN 60309
- Mounting: Panel installation with secure fixing points
Easy Installation
Installing the Makewell Tech 32A 3 Pin Panel Socket is quick and reliable:
- Prepare the Panel: Cut an opening according to the provided dimensions.
- Connect Terminals: Strip insulation and insert conductors into the clearly marked terminals (L, N, E).
- Secure the Terminals: Tighten all screws to create solid electrical contact.
- Mount the Socket: Fasten securely into the panel using appropriate hardware.
- Test Connections: Use a continuity tester to confirm correct wiring before energizing.
- Important: Installation must be performed by a qualified electrician to comply with safety regulations.
Why Choose Makewell Tech?
At Makewell Tech, we combine engineering expertise with a commitment to durability and safety. The 32A 3 Pin Panel Socket is your dependable solution for industrial power distribution—helping you maintain productivity and avoid costly downtime.
